Atlas

class: title

# Atlas ORM
## A Persistence-Layer Data Mapper

![Atlas Logo](./images/atlas-128.png)

### Paul M. Jones
### <https://github.com/atlasphp/Atlas.Orm>

---

# Objects and Tables

- Moving complex data from SQL to PHP is troublesome

- OOP fundamentally different from relational algebra

- Evolved data-source patterns to deal with this

---

# Data Source Architecture

.right-column[![DDD](./images/poeaa.jpg)]

- Row Data Gateway: row data and peristence logic

- Active Record: row data, persistence logic, and domain logic

- Table Data Gateway: all table rows, and persistence logic

- Data Mapper: persistence logic for a disconnected domain object

---

# Domain Logic

.right-column[![DDD](./images/ddd.jpg)]

- Domain "should not" be modeled on database structure

- Keep domain objects separated from database connections

- Converting between database and domain is very difficult

- ["Object-Relational Impedance Mismatch"](https://en.wikipedia.org/wiki/Object-relational_impedance_mismatch)

---

# ORMs

- Ease conversion of relational rows to domain objects

- Generate SQL, retrieve/save data, map data to objects

- Active Record (persistence combined with domain logic)

- Data Mapper (persistence separated from domain objects)

---

# Tradeoffs (Active Record)

- Easy to start with for CRUD/BREAD

- Easy to add simple domain logic

- As complexity increases, need separate domain layer

- Hard to extract domain behavior from perisistence

- Harder to maintain and refactor

---

# Tradeoffs (Data Mapper)

- Clear separation between persistence and domain

- Easier to maintain as complexity increases

- Harder to get started with

- Presumes rich domain model and mapping expertise

- Too much for early CRUD/BREAD operations

---

# The Underlying Problem

- All systems start simple

- Some systems become complex

- Can't tell in advance

- Want a low-cost path *in case of* complexity

---

# Desiderata

- Easy to get started with

- Clear refactoring path if complexity increases

- Amenable to CRUD/BREAD in early stages

- Ability to add simple behaviors

- Strategy to convert from ORM to Domain Model proper

- Maintain separation of persistence from data

---

# Persistence Model, not Domain Model

- Use the Data Mapper approach for separation

- Instead of mapping to *domain* model entities (Aggregates) ...

- ... map to the *persistence* model rows and relationships (Records)

---

# Atlas

- A data mapper for your persistence model

- Build a series of Table Data Gateway

- Relate them to each other via Mappers

- Retrieve and save Record objects through the Mapper objects

---

# Mapper Object

```
<?php
namespace App\DataSource\Thread;

use App\DataSource\Author\AuthorMapper;
use App\DataSource\Summary\SummaryMapper;
use App\DataSource\Reply\ReplyMapper;
use App\DataSource\Tagging\TaggingMapper;
use App\DataSource\Tag\TagMapper;
use Atlas\Orm\Mapper\AbstractMapper;

class ThreadMapper extends AbstractMapper
{
    protected function setRelated()
    {
        $this->manyToOne('author', AuthorMapper::CLASS);
        $this->oneToOne('summary', SummaryMapper::CLASS);
        $this->oneToMany('replies', ReplyMapper::CLASS);
        $this->oneToMany('taggings', TaggingMapper::CLASS);
        $this->manyToMany('tags', TagMapper::CLASS, 'taggings');
    }
}
```

---

# Atlas Container

```
<?php
$container = new \Atlas\Orm\AtlasContainer(
    'mysql:dbname=testdb;host=localhost',
    'username',
    'password'
);

$container->setMappers(
    \App\DataSource\Author\AuthorMapper::CLASS,
    \App\DataSource\Summary\SummaryMapper::CLASS,
    \App\DataSource\Reply\ReplyMapper::CLASS,
    \App\DataSource\Thread\ThreadMapper::CLASS,
    \App\DataSource\Tagging\TaggingMapper::CLASS,
    \App\DataSource\Tag\TagMapper::CLASS,
);

$atlas = $container->newAtlas();
```

---

# CRUD/BREAD Retrieval with Relatonships

```
$threads = $atlas->select(ThreadMapper::CLASS)
    ->limit(10)
    ->orderBy(['date DESC'])
    ->with([
        'author',
        'replies' => function ($replies) {
            $replies
                ->orderBy(['date ASC'])
                ->with(['author']);
        };
        'taggings',
        'tags',
    ])
    ->fetchRecordSet();

foreach ($threads as $thread) {
    echo "{$thread->title} by {$thread->author->first_name} "
        . "has " count($thread->replies) . " replies.";
}
```

---

# CRUD/BREAD Saving

```
$thread = $atlas->newRecord(ThreadMapper::CLASS);
$thread->title = 'New Title';
$atlas->insert($thread);
echo $thread->thread_id;

$thread = $atlas->fetchRecord(ThreadMapper::CLASS, $threadId);
$thread->title = 'Changed Title';
$atlas->update($thread);

$thread = $atlas->fetchRecord(ThreadMapper::CLASS, $threadId);
$atlas->delete($thread);
```

---

# Adding Simple Behaviors

```
<?php
namespace App\DataSource\Author;

use Atlas\Orm\Mapper\Record;

class AuthorRecord extends Record
{
    public function getFullName()
    {
        return $this->first_name . ' ' . $this->last_name;
    }
}
```

---

# Richer Domain Models

```
<?php
namespace App\Domain\Thread;

use App\DataSource\Thread\ThreadMapper;

class ThreadRepository
{
    protected $mapper;

public function __construct(ThreadMapper $mapper)
    {
        $this->mapper = $mapper;
    }

public function fetchThread($thread_id)
    {
        $record = $this->mapper->fetchRecord(...);
        return $this->newThread($record);
    }

protected function newThread(ThreadRecord $record)
    {
        /* ??? */
    }
}
```

---

# Compose Persistence Into Domain
```
class ThreadRepository
{
    protected function newThread(ThreadRecord $record)
    {
        return new ThreadAggregate($record);
    }
}
```

---

# Map From Persistence To Domain

```
class ThreadRepository
{
    protected function newThread(ThreadRecord $record)
    {
        return new ThreadAggregate(
            $record->thread_id,
            $record->title,
            $record->body,
            $record->date_published,
            $record->author->author_id,
            $record->author->name,
            $record->tags->getArrayCopy(),
            $record->replies->getArrayCopy()
        );
    }
}
```

---

class: middle

# Thanks!

- Repo: https://github.com/atlasphp/Atlas.Orm
- Docs: https://github.com/atlasphp/Atlas.Orm/blob/1.x/docs/index.md
- @pmjones on Twitter and Gab
- http://paul-m-jones.com
