# Atlas ORM
## Doing The Heavy Lifting For Your Persistence Layer

![Atlas Logo](./images/atlas-128.png)

### Paul M. Jones
### <http://atlasphp.io>

---

# About Me

- 8 years USAF Intelligence
- BASIC in 1983, PHP since 1999
- Jr. Developer, VP Engineering
- Aura, ZF, Relay, Radar
- PSR-1, PSR-2, PSR-4
- [Action-Domain-Responder](http://pmjones.io/adr)
- [MLAPHP](https://leanpub.com/mlaphp)

---

# Objects and Tables

- Moving complex data from SQL to objects and back is tough

- OOP fundamentally different from relational algebra

- Evolved data-source patterns to deal with this

---

# Data Source Architecture

- [Row Data Gateway](https://martinfowler.com/eaaCatalog/rowDataGateway.html):
  one table row, and persistence logic

- [Active Record](https://martinfowler.com/eaaCatalog/activeRecord.html):
  one table row, persistence logic, and domain logic

- [Table Data Gateway](https://martinfowler.com/eaaCatalog/tableDataGateway.html):
  all table rows, and persistence logic

- [Data Mapper](https://martinfowler.com/eaaCatalog/dataMapper.html):
  persistence logic for a disconnected in-memory object

---

# Domain Logic

- Domain "should not" be modeled on database structure

- Keep domain objects separated from database connections

- Converting between database and domain is very difficult

- ["Object-Relational Impedance Mismatch"](https://en.wikipedia.org/wiki/Object-relational_impedance_mismatch)

---

# Plain Old SQL?

- Write queries by hand

- Map to object by hand

- Fine control, time consuming

- Relationships difficult

---

# Object-Relational Mappers (ORMs)

- Ease conversion of relational rows to domain objects

- Generate SQL, retrieve/save data, map data to objects

- Active Record (persistence combined with domain logic)

- Data Mapper (persistence separated from domain objects)

---

# Tradeoffs (Active Record)

- Easy to start with for CRUD/BREAD

- Easy to add simple domain logic

- As complexity increases, need separate domain layer

- Hard to extract domain behavior from perisistence

- Harder to maintain and refactor

---

# Tradeoffs (Data Mapper)

- Clear separation between persistence and domain

- Easier to maintain as complexity increases

- Harder to get started with

- Presumes rich domain model and mapping expertise

- Too much for early CRUD/BREAD operations

---

# The Underlying Problem

- All systems start simple

- Some systems become complex

- Can't tell in advance

- Want a low-cost path *in case of* complexity

---

# Desiderata

- Easy to get started with

- Clear refactoring path if complexity increases

- Amenable to CRUD/BREAD in early stages

- Ability to add simple behaviors

- Strategy to convert from ORM to Domain Model proper

- Maintain separation of persistence from data

---

# Persistence Model, not Domain Model

- Thanks, [Mehdi Khalili](https://www.mehdi-khalili.com/orm-anti-patterns-part-4-persistence-domain-model)

- Use the Data Mapper approach for separation

- Instead of mapping to *domain* model Entities & Aggregates ...

- ... map to the *persistence* model rows & relationships (Records)

- Then build domain objects from persistence objects, when needed

---

# Atlas

- A data mapper for your persistence model

- Retrieve and save Row objects through Table Data Gateways

- Identity map for Rows on primary keys (incl. composite keys)

- Define relationships between tables (Row + Related = Record)

- Retrieve and save Record objects through the Mappers

---

# Atlas From The Ground Up

---

# Installation

All-purpose:

```bash
$ composer require atlas/orm ~3.0
$ composer require --dev atlas/cli ~2.0
```

Symfony:

```bash
$ composer require atlas/symfony ~1.0
```

Slim: [cookbook](https://www.slimframework.com/docs/v3/cookbook/database-atlas.html)

---

# Tables

```sql
CREATE TABLE authors (
    author_id INTEGER PRIMARY KEY AUTOINCREMENT,
    first_name VARCHAR(50),
    last_name VARCHAR(50)
);

CREATE TABLE threads (
    thread_id INTEGER PRIMARY KEY AUTOINCREMENT,
    author_id INTEGER NOT NULL,
    created_at DATETIME,
    updated_at DATETIME,
    title VARCHAR(100),
    body TEXT
);

CREATE TABLE summaries (
    thread_id INTEGER PRIMARY KEY AUTOINCREMENT,
    reply_count INTEGER,
    view_count INTEGER
);

```

---

```sql
CREATE TABLE replies (
    reply_id INTEGER PRIMARY KEY AUTOINCREMENT,
    thread_id INTEGER NOT NULL,
    author_id INTEGER NOT NULL,
    body TEXT
);

CREATE TABLE taggings (
    tagging_id INTEGER PRIMARY KEY AUTOINCREMENT,
    thread_id INTEGER,
    tag_id INTEGER
);

CREATE TABLE tags (
    tagging_id INTEGER PRIMARY KEY AUTOINCREMENT,
    name VARCHAR(20)
);
```

---

# Skeleton Generator

Skeleton Config:

```php
<?php
return [
    'pdo' => [
        'mysql:dbname=testdb;host=localhost',
        'username',
        'password',
    ],
    'namespace' => 'App\\DataSource',
    'directory' => './src/App/DataSource',
];
```

Skeleton Command:

```bash
$ php ./vendor/bin/atlas-skeleton.php /path/to/skeleton-config.php
```

---

# Generated Files

```
└── src
    └── App
        └── DataSource
            └── Thread
                ├── Thread.php                  # mapper
                ├── ThreadEvents.php
                ├── ThreadFields.php
                ├── ThreadRecord.php
                ├── ThreadRecordSet.php
                ├── ThreadRelationships.php     # relationships
                ├── ThreadRow.php
                ├── ThreadSelect.php
                ├── ThreadTable.php             # table
                ├── ThreadTableEvents.php
                └── ThreadTableSelect.php
```

---

# Table Class

```php
namespace App\DataSource\Thread;

use Atlas\Table\Table;

/**
 * @method ThreadRow|null fetchRow($primaryVal)
 * @method ThreadRow[] fetchRows(array $primaryVals)
 * @method ThreadTableSelect select(array $whereEquals = [])
 * @method ThreadRow newRow(array $cols = [])
 * @method ThreadRow newSelectedRow(array $cols)
 */
class ThreadTable extends Table
{
    const DRIVER = 'mysql';

const NAME = 'threads';
```

---

```php
    const COLUMNS = [
        'thread_id' => [
            'name' => 'thread_id',
            'type' => 'INTEGER',
            'size' => null,
            'scale' => null,
            'notnull' => false,
            'default' => null,
            'autoinc' => true,
            'primary' => true,
            'options' => null,
        ],

// ...

'body' => [
            'name' => 'body',
            'type' => 'TEXT',
            'size' => null,
            'scale' => null,
            'notnull' => true,
            'default' => null,
            'autoinc' => false,
            'primary' => false,
            'options' => null,
        ],
    ];
```

---
```php
    const COLUMN_NAMES = [
        'thread_id',
        'author_id',
        'subject',
        'body',
    ];

const COLUMN_DEFAULTS = [
        'thread_id' => null,
        'author_id' => null,
        'subject' => null,
        'body' => null,
    ];

const PRIMARY_KEY = [
        'thread_id',
    ];

const AUTOINC_COLUMN = 'thread_id';

const AUTOINC_SEQUENCE = null;
}
```

---

# Mapper Class

```php
namespace App\DataSource\Thread;

use Atlas\Mapper\Mapper;

/**
 * @method ThreadTable getTable()
 * @method ThreadRelationships getRelationships()
 * @method ThreadRecord|null fetchRecord($primaryVal, array $with = [])
 * @method ThreadRecord|null fetchRecordBy(array $whereEquals, array $with = [])
 * @method ThreadRecord[] fetchRecords(array $primaryVals, array $with = [])
 * @method ThreadRecord[] fetchRecordsBy(array $whereEquals, array $with = [])
 * @method ThreadRecordSet fetchRecordSet(array $primaryVals, array $with = [])
 * @method ThreadRecordSet fetchRecordSetBy(array $whereEquals, array $with = [])
 * @method ThreadSelect select(array $whereEquals = [])
 * @method ThreadRecord newRecord(array $fields = [])
 * @method ThreadRecord[] newRecords(array $fieldSets)
 * @method ThreadRecordSet newRecordSet(array $records = [])
 * @method ThreadRecord turnRowIntoRecord(Row $row, array $with = [])
 * @method ThreadRecord[] turnRowsIntoRecords(array $rows, array $with = [])
 */
class Thread extends Mapper
{
}
```

---

# Relationship Class

```php
namespace App\DataSource\Thread;

use App\DataSource\Author\Author;
use App\DataSource\Reply\Reply;
use App\DataSource\Summary\Summary;
use App\DataSource\Tag\Tag;
use App\DataSource\Tagging\Tagging;
use Atlas\Mapper\MapperRelationships;

class ThreadRelationships extends MapperRelationships
{
    protected function define()
    {
        $this->manyToOne('author', Author::CLASS);

$this->oneToOne('summary', Summary::CLASS);

$this->oneToMany('replies', Reply::CLASS);

$this->oneToMany('taggings', Tagging::CLASS);

$this->manyToMany('tags', Tag::CLASS, 'taggings');
    }
}
```

---

# Relationship Control

```php
class FooRelationships extends MapperRelationships
{
    protected function define()
    {
        // ON and WHERE
        $this->oneToMany('bars', Bar::CLASS, [
                'foo_col_1' => 'bar_col_1',
                'foo_col_2' => 'bar_col_2',
            ])
            ->where('bar_col = ', 'baz');

// "polymorphic"
        $this->manyToOneVariant('commentable', 'commentable_type')
            ->type('page', Page::CLASS, ['commentable_id' => 'page_id'])
            ->type('post', Post::CLASS, ['commentable_id' => 'post_id'])
            ->type('video', Video::CLASS, ['commentable_id' => 'video_id']);

// oneToOneBidi (bidirectional)
    }
}
```

---

# Atlas: Fetch, Update, Delete

```php
use Atlas\Orm\Atlas;

/* instantiate */
$atlas = Atlas::new(
    'mysql:dbname=testdb;host=localhost',
    'username',
    'password'
);

/* fetch */
$thread = $atlas->fetchRecord(Thread::CLASS, 1, [
    'author',
    'tags'
]);

/* update */
$thread->title = 'New Title';
$atlas->update($thread);

/* delete */
$atlas->delete($thread);
```

---

# Create and Insert

```php
/* a new author */

$author = $atlas->newRecord(Author::CLASS);

$author->first_name = 'Bolivar';
$author->last_name = 'Shagnasty';

echo $author->author_id; // null
$atlas->insert($author);
echo $author->author_id; // 1

/* a new thread by an existing author */

$author = $atlas->fetchRecord(Author::CLASS, 1);

$thread = $atlas->newRecord(Thread::CLASS);
$thread->title = 'My Frist Thraed';

$thread->author = $author; // related field object

echo $thread->author_id; // null
$atlas->insert($thread);
echo $thread->author_id; // 1
```

---

# Full Record Persistence

```php
$thread = $atlas->fetchRecord(
    Thread::CLASS,
    $thread_id,
    [
        'author',
        'replies' => [
            'author',
        ],
        'tags',
    ]
);

$reply_author = $atlas->fetchRecord(
    Author::CLASS,
    $reply_author_id
);

$reply = $thread->replies->appendNew([
    'body' => $reply_body,
    'thread' => $thread,
    'author' => $reply_author,
]);

$atlas->persist($thread);
```

---

# Fetch Sets With Relationships

```php
$threads = $atlas->fetchRecordSet(
    Thread::CLASS,
    [1, 2, 3, 4, 5]
    [
        'author',
        'replies' => [
            'author',
        ]
    ]
);

foreach ($threads as $thread) {
    echo "{$thread->title} by {$thread->author->first_name} "
        . "has " count($thread->replies) . " replies.";
}
```

Total of 4 queries (no N+1 trouble)

---

# Powerful SELECT Functionality

```php
$threads = $atlas
    ->select(Thread::CLASS)
    ->orderBy('date DESC')
    ->page(1)
    ->paging(10)
    ->with([
        'author',
        'replies' => function ($replies) {
            $replies
                ->orderBy('date ASC')
                ->with(['author'])
                ->limit(10);
        },
        'tags'
    ])
    ->fetchRecordSet();
```

---

# Direct SELECT Queries ...

```php
$select = $atlas
    ->select(Foo::CLASS) // "from"
    ->columns(...)
    ->join(...)
    ->joinWith(...)
    ->where(...)
    ->groupBy(...)
    ->having(...)
    ->orderBy(...)
    ->limit(...)
    ->offset(...);
```

---

# ... And Non-Record Fetching

```php
$select->fetchRow();     // Row object
$select->fetchRows();    // Array of Row objects

$select->fetchAll();     // Seq array of rows as assoc arrays
$select->fetchAssoc();   // Assoc array of rows as assoc arrays
$select->fetchColumn();  // Column as seq array
$select->fetchKeyPair(); // First 2 columns as key-value pairs
$select->fetchOne();     // First row as assoc array
$select->fetchValue();   // First col of first row

$select->yieldAll();     // Generator over fetchAll()
$select->yieldAssoc();   // Generator over fetchAssoc()
$select->yieldColumn();  // Generator over fetchColumn()
$select->yieldKeyPair(); // Generator over fetchKeyPair()
```

---

# Access to Every Layer

```php
$atlas
    ->mapper(Foo::CLASS) // Atlas\Mapper\Mapper
    ->getTable() // Atlas\Table\Table
    ->getReadConnection() // Atlas\Pdo\Connection
    ->getPdo(); // PDO
```

---

# Persistence Behaviors

---

# Lower-Level Table Events

- SELECT
    - `modifySelect()`
    - `modifySelectedRow()`

- INSERT/UPDATE/DELETE
    - `modifyInsert()`
    - `beforeInsertRow()`
    - `modifyInsertRow()`
    - `afterInsertRow()`

---

# Modifying Rows Before Persistence

```php
namespace App\DataSource\Thread;

use Atlas\Table\Row;
use Atlas\Table\TableEvents;

class ThreadTableEvents extends TableEvents
{
    public function beforeInsertRow(Table $table, Row $row)
    {
        $row->created_at = date('Y-m-d H:i:s');
    }

public function beforeUpdateRow(Table $table, Row $row)
    {
        $row->updated_at = date('Y-m-d H:i:s');
    }
}
```

---

# Modifying Queries During Persistence

```php
namespace App\DataSource\Foo;

use Atlas\Query\Insert;
use Atlas\Query\Update;
use Atlas\Table\Row;
use Atlas\Table\TableEvents;
use Cryptor;

class FooTableEvents extends TableEvents
{
    public function modifySelectedRow(Row $row)
    {
        $row->sensitive = Cryptor::decrypt($row->sensitive);
    }

public function modifyInsertRow(Table $table, Row $row, Insert $insert)
    {
        $insert->column('sensitive', Cryptor::encrypt($row->sensitive));
    }

public function modifyUpdateRow(Table $table, Row $row, Update $update)
    {
        $update->column('sensitive', Cryptor::encrypt($row->sensitive));
    }
}
```

---

# Transaction Strategies

- AutoCommit (manual BEGIN/COMMIT/ROLLBACK)
- AutoTransact (each Atlas write; fully automatic)
- BeginOnWrite (manual COMMIT/ROLLBACK)
- BeginOnRead (manual COMMIT/ROLLBACK)

---

# Domain Modeling

---

# Adding Domain Behaviors

- Directly in persistence model
- Compose persistence into domain
- Map between persistence and domain

---

# Adding Record Methods

```php
namespace App\DataSource\Author;

use Atlas\Mapper\Record;

class AuthorRecord extends Record
{
    public function getFullName()
    {
        return $this->first_name . ' ' . $this->last_name;
    }
}
```

---

# Adding RecordSet Methods

```php
namespace App\DataSource\Author;

use Atlas\Mapper\RecordSet;

class AuthorRecordSet extends RecordSet
{
    public function getAllNames()
    {
        $result = [];
        foreach ($this as $author) {
            $result[] = $author->getFullName();
        }
        return $result;
    }
}
```

---

# Richer Domain Models

```php
namespace App\Domain\Conversation;

use Atlas\Orm\Atlas;
use App\DataSource\Thread\Thread;
use App\DataSource\Thread\ThreadRecord;

class ConversationRepository
{
    protected $atlas;

public function __construct(Atlas $atlas)
    {
        $this->atlas = $atlas;
    }

public function fetchConversation($id) : ConversationInterface
    {
        $record = $this->atlas->fetchRecord(Thread::CLASS, $id);
        return $this->newConversation($record);
    }

protected function newConversation(ThreadRecord $record) : ConversationInterface
    { /* ??? */ }
}
```

---

# Conversation

```php
namespace App\Domain\Conversation;

use DateTimeImmutable;

class ConversationInterface
{
    public function getId() : int;
    public function getTitle() : string;
    public function getBody() : string;
    public function getDatePublished() : DateTimeImmutable;
    public function getAuthorName() : string;
    public function getReplies() : array;
}
```

---

# Compose Persistence Into Domain

```php
namespace App\Domain\Conversation;

use App\DataSource\Thread\ThreadRecord;

class Conversation implements ConversationInterface
{
    protected $record;

public function __construct(ThreadRecord $record)
    {
        $this->record = $record;
    }

public function getId() : int
    {
        return $this->record->thread_id;
    }

public function getTitle() : string
    {
        return $this->record->title;
    }
```

---

```php
    public function getBody() : string
    {
        return $this->record->body;
    }

public function getDatePublished() : DateTimeImmutable
    {
        return new DateTimeImmutable($this->record->created_at);
    }

public function getAuthorName() : string
    {
        return $this->record->author->getFullName();
    }

public function getReplies() : array
    {
        return $this->record->replies->getArrayCopy();
    }
}
```

---

```php
class ConversationRepository
{
    // ...

protected function newConversation(ThreadRecord $record) : ConversationInterface
    {
        return new Conversation($record);
    }
}
```

---

# Map From Persistence To Domain

```php
namespace App\Domain\Conversation;

use App\DataSource\Thread\ThreadRecord;

class Conversation implements ConversationInterface
{
    protected $id;
    protected $title;
    protected $body;
    protected $datePublished;
    protected $authorName;
    protected $replies;
```

---

```php
    public function __construct(
        string $title,
        string $body,
        DateTimeImmutable $datePublished,
        string $authorName,
        array $replies,
        int $id = null
    ) {
        $this->title = $title;
        $this->body = $body;
        $this->datePublished = $datePublished;
        $this->authorName = $authorName;
        $this->replies = $replies;
        $this->id = $id;
    }

public function getId()
    {
        return $this->id;
    }

public function getTitle()
    {
        return $this->title;
    }
```

---

```php
    public function getBody()
    {
        return $this->body;
    }

public function getDatePublished()
    {
        return $this->datePublished;
    }

public function getAuthorName()
    {
        return $this->authorName;
    }

public function getReplies()
    {
        return $this->replies;
    }
}
```

---

```php
class ConversationRepository
{
    // ...

protected function newConversation(ThreadRecord $record) : ConversationInterface
    {
        return new Conversation(
            $record->title,
            $record->body,
            new DateTimeImmutable($record->date_published),
            $record->author->getFullName(),
            $record->replies->getArrayCopy(),
            $record->thread_id
        );
    }
}
```

---

# Conclusion

- Tabular data is hard to represent in OOP
- Different data-source architectures and their tradeoffs
- How Atlas meets in the middle as a persistence data mapper
- Functionality available through persistence modeling
- Refactoring from persistence model toward domain model

---

# Thanks!

- Repo: https://github.com/atlasphp/Atlas.Orm
- Docs: https://atlasphp.io
- http://paul-m-jones.com
